13.56MHz RFID Recognition System Read Write Head With RS-485 LED Display And M30

Name: 1356MHz RFID Recognition System Read Write Head With RS485 LED Display And M30
Brand: KRONZ
Price: 1 USD

Buy cheap 13.56MHz RFID Recognition System Read Write Head With RS-485 LED Display And M30 product

Model Number : KRH-M30G-R4

Place of Origin : Guangdong, China

Brand Name : KRONZ

Price : Negotiable

Certification : CE

MOQ : 10 pieces

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000 pieces per month

Delivery Time : 5-8 working days

Packaging Details : Paper box packing

Series : M30 Series

Features : High reading and writing speed

Description : RFID HF Read/write Head

Operating Temperature : -30℃~+70℃

Voltage Rating : 18-30V

Interface : M12 4 Pin Male Connector

Operating frequency : 13.56MHz

Supply voltage : 9-30VDC

Contact Now

13.56MHz RFID Recognition System Read Write Head With RS-485 LED Display And M30

Product Overview

This high-performance RFID HF read/write head features fast reading and writing speeds with an integrated antenna and LED display, designed for industrial applications.

Key Features

M30 Series industrial-grade construction
High reading and writing speed performance
13.56MHz operating frequency
RS-485 communication interface
Blue LED status indicator
Robust IP67 protection rating

13.56MHz RFID Recognition System Read Write Head With RS-485 LED Display And M30

Technical Specifications

Model No.	KRH-M30G-R4
Operating frequency	13.56MHz
Read/Write range	0-70mm (tag dependent)
ISO standard	ISO 15693
Supply voltage	9-30VDC
Current consumption	<60mA@24V
Communication interface	RS-485
Transmission speed	9600-115200 bps
Connector	4Pin-M12-ACODED-Male
Operation temperature	-30℃ to +70℃
Degree of protection	IP67 (EN 60529)
Housing Material	Brass nickel plated (metal) + Nylon (plastic)
Dimensions	M30 x 1.5/L=65mm
Certifications	CE, FCC, RoHS, WEEE

Environmental Specifications

Attribute	Specification
Shock resistance	7M2,500 m/s² (EN 60721-3-7)
Vibration resistance	7M2,200 m/s² (EN 60721-3-7)
Storage temperature	-40℃ to +85℃
